Zero Distortion Cylindrical Bullet Head Mini USB Camera 1080p OTG Android Camera

Name: Zero Distortion Cylindrical Bullet Head Mini USB Camera 1080p OTG Android Camera
Brand: Shenzhen Huachuang Micro Vision Technology Co., Ltd.
SKU: HCU-BT202AZ
Price: 35.29 USD
Availability: InStock

Brand Name:	HCVsight
Model Number:	HCU-BT202AZ
MOQ:	50 pieces
Price:	US$38.99/50~199 pieces US$37.09/200~499 pieces US$35.29/500~999 pieces
Payment Terms:	T/T
Supply Ability:	100000/pieces/mouth

Detail Information

Product Description

Detail Information

Place of Origin:

ShenZhen，China

Pixel:

2mp

Compatibility:

Windows/Mac OS/Linux/Andriod

Frame Rate:

30fps

Color:

Black

Product Dimensions:

20mmX77mm(Base Size Is Not Included)

Sensor Type:

CMOS

Working Voltage:

DC 5V

Interface Type:

Andriod

Agreement:

UVC

Packaging Details:

Anti-static bag in Paper box（110mmx93mm41mm）

Supply Ability:

100000/pieces/mouth

Highlight:

Compact USB Camera

Plug and Play Micro HD Camera

Android Interface Surveillance Camera

Product Description

Zero Distortion Cylindrical Bullet Head Mini USB Camera 1080p OTG Android Camera

Product Introduction

This zero distortion cylindrical bullet USB camera perfectly blends professional optical performance with ultimate portability design. Equipped with a high-quality 2-megapixel sensor, it can output true 1080P full HD image quality. The unique cylindrical bullet head design combined with a precision 3mm distortion free lens effectively eliminates edge distortion and presents a realistic image of the center and surroundings. Plug and play, perfectly compatible with Android OTG devices, and supports audio transmission,By seamlessly connecting with Android devices, users can easily achieve remote control and monitoring of cameras using common Android terminals such as smartphones, tablets, etc. No complex operating procedures are required. Simply install the corresponding application on the Android device to view the photos taken by the camera anytime, anywhere, and achieve remote control of lens direction, zoom, and other functions, truly realizing blind spot free remote real-time monitoring.

Key Features

1080P Full HD Zero Distortion Image Quality: Equipped with a 2-megapixel high-definition CMOS sensor, supporting 1920x1080 resolution, providing clear and delicate images. The 3mm fixed focus lens with a special optical structure has a viewing angle of 95 ° and can significantly reduce the common edge stretching and deformation of ordinary wide-angle lenses, bringing a more realistic and deformation free visual experience.
Classic cylindrical bullet head design: with a professional and compact appearance. The product size is 20mm x 77mm (diameter * length), exquisite and compact, easy to install and carry, and can be easily fixed in various scenarios.
Plug and play, widely compatible with Android devices: can be connected to Android smartphones, tablets, and other devices through an OTG adapter cable. No need for additional drivers, automatic recognition, instantly turning your mobile device into a high-definition surveillance camera or video call device.
Built in microphone, supports audio synchronization: While capturing high-definition images, it can also synchronously record environmental sounds, achieving synchronous recording and transmission of audio and video, making video content more vivid and complete.

Technical Specifications

Parameter	Specification
Sensor	1/2.9"
Pixel	2MP
Compression format	MJPG/YUV2
Frame rate	1920x1080 30fps
Operating voltage	DC 12v
Dimensions	20mm × 77mm (Base size not included)
Operating temperature	<70°C
Power consumption	0.25w
Model No	HCU-BT202AZ
Lens Specifications	EFL:3mm, F.ON:2.2, Thread size:M12, Element:4E+IR, Angle:D=95° H=83° V=55°
Supported OS	WinXP/Mac OS/Linux/Win7/Win8/Win10/Android

Application Scenarios

Ideal for machine vision and equipment monitoring applications including: ATM systems, banking operations, hospital reporting, vending machines, digital signage, robotics, industrial automation, fire monitoring systems, security surveillance, and various embedded systems.

Customization Options

Brand: HCVsight
Model: HCU-BT202AZ
Origin: Shenzhen, China
MOQ: Negotiable
Delivery: 2-3 weeks
Packaging: Anti-static bag in paper box (110×93×41mm)

We are well aware of the unique visual requirements of different applications and provide comprehensive OEM/ODM customization services to help you create differentiated products.

1. Lens customization: specific focal length, field of view angle, distortion control.
2. Customized casing: Design a dedicated casing, bracket, or fixing method based on the structure of your device.
3. Cable and Interface: Customize cable length and interface type (such as USB and Android).
4. Pixel customization: Different resolution and frame rate models are available (such as higher pixel 4MP, 5MP, 8MP, 12MP).

Support & Services

Our comprehensive support includes:

Online documentation and user manuals
Email and phone technical support
Remote desktop assistance
Product training and customized solutions

Lens specification sheet:Specification for 3.6mm lens.pdf

About our more products:Huachuang Finished Product List.xls
