| Brand Name: | HCVsight |
| Model Number: | HCU-BT181TPC |
| MOQ: | 50 pieces |
| Price: | US$32.69/50~199 pieces US$31.09/200~499 pieces US$29.59/500~999 pieces |
| Payment Terms: | T/T |
| Supply Ability: | 100000/pieces/mouth |
| Specification | Detail |
|---|---|
| Sensor | 1/4" |
| Pixel | 1MP |
| Compression format | MJPG/YUV2 |
| Frame rate | 1280x720 30fps |
| Audio | none |
| Operating voltage | DC 5v |
| Product dimensions |
19mmx43mm |
| White balance | Automatic |
| Operating temperature | <70°C |
| Power consumption | 0.25w |
| Model No | HCU-BT181 |
| Interface type | Type-C |
| Lens | EFL:3mm F.ON:2.2 Distortion: <-1.0% Element:4E+IR |
| FOV | 90° |
| Chip Type | CMOS |
| Supported OS | WinXP/Mac OS/Linux/Win7/Win8/Win10/Android |
FAQ
Q: What types of cameras do you manufacture?
A: We specialize in manufacturing high-performance USB/IP/analog cameras and camera modules for machine vision, including:
Embedded cameras for face/object/barcode recognition
Industrial cameras for automated inspection and measurement
Security vision cameras for surveillance and monitoring
Q: Can you customize cameras?
A: Yes! We offer OEM/ODM services and can customize:
- Resolution (1MP ~ 12MP+)
- Interface Type (USB 2.0/3.0, Type-C, Micro USB, RJ45, PoE Power, BNC, Dubon, etc.)
- Lens Options (Fixed Focus, Autofocus, Wide-Angle, Telephoto, etc.)
- SDK Support (Provides software support for secondary development and system integration)
- Housing Material (Metal/Plastic, supports waterproof, dustproof, and other industrial-grade designs)
- Module Solutions (Customizable embedded camera modules suitable for different application scenarios)
Q: How is the quality control?
A: All cameras undergo rigorous testing (EIS, low-light performance, durability) and comply with CE/FCC/RoHS.
Q: What is the lead time?
A:In-stock items: 3-7 days. Custom orders: 2-4 weeks (depending on specifications).
