| Brand Name: | HCVsight |
| Model Number: | HCU-ZDT202TPC |
| MOQ: | 50 pieces |
| Price: | US$36.89/50~199 pieces US$35.09/200~499 pieces US$31.59/500~999 pieces |
| Payment Terms: | T/T |
| Supply Ability: | 100000/pieces/mouth |
| Sensor | 1/2.9" |
| Pixel | 2MP |
| Compression Format | MJPG/YUV2 |
| Frame Rate | 1920*1080 @ 30 fps |
| Audio | Supported |
| Power | DC 5V |
| Interface | Type-C |
| Lens | EFL:3mm, Focal Length:2.2, Distortion:<-1.0% |
| FOV | 90°(Customizable) |
| Product Size | 20mmx65mm (Base size not included) |
| Working Temperature | <70°C |
| Power Consumption | 0.25W |
| Model | HCU-ZDT202TPC |
| Agreement | UVC |
| Compatibility | Windows/Mac OS/Linux/Android |
Core advantages of the product
1. Compact Industrial-Grade Design: Featuring a compact bullet-shaped housing, its mini size allows engineers to easily embed the USB camera module into products without redesigning the internal structure.
2. Low-Distortion Lens for True 1080p HD Image Quality: The integrated high-sensitivity sensor delivers full HD 1080p output, producing clear, sharp, and color-accurate images suitable for real-time monitoring and data analysis.
3. UVC Driverless and Universal Compatibility: No driver installation required; compatible with Android OTG devices (phones/tablets supporting Type-C OTG), Windows PCs and laptops, macOS, Linux embedded platforms, and other operating systems.
4. Type-C OTG Plug and Play for Android Devices: Utilizing a USB Type-C interface, it supports fast and stable data transfer and ensures reliable connectivity with Android smartphones and tablets through OTG functionality.
Industrial automation and machine vision, precision equipment status monitoring, security monitoring, embedded intelligent access control/attendance systems, miniaturized concealed monitoring equipment, vehicle mobile monitoring, smart home security, endoscope assisted imaging, laboratory equipment monitoring, small traffic monitoring equipment, intelligent retail terminals, drone/robot visual perception, education/conference system cameras, various embedded devices that require compact visual solutions, advertising machines, all-in-one machines, intelligent electronic scales, automatic welding equipment, fire water guns, external law enforcement instruments, external cameras for Android phones, computer cameras, high-speed cameras, etc.
We are well aware of the unique visual requirements of different applications and provide comprehensive OEM/ODM customization services to help you create differentiated products.
1. Lens customization: specific focal length, field of view angle, distortion control.
2. Customized casing: Design a dedicated casing, bracket, or fixing method based on the structure of your device.
3. Cable and Interface: Customize cable length and interface type.
4. Pixel customization: Different resolution and frame rate models are available (such as higher pixel 4MP, 5MP, 8MP, 12MP).
FAQ
Q: What types of cameras do you manufacture?
A: We specialize in manufacturing high-performance USB/IP/analog cameras and camera modules for machine vision, including:
Embedded cameras for face/object/barcode recognition
Industrial cameras for automated inspection and measurement
Security vision cameras for surveillance and monitoring.
Q: Which industries do you serve?
A: Our cameras are widely used in:
✔ Industrial automation (defect detection, robotics)
✔ Smart security (facial recognition, access control)
✔ Retail/logistics (barcode scanning, inventory management)
✔ Medical equipment and traffic monitoring
Q: Can you customize cameras?
A: Yes! We offer OEM/ODM services and can customize:
- Resolution (1MP ~ 12MP+)
- Interface Type (USB 2.0/3.0, Type-C, Micro USB, RJ45, PoE Power, BNC, Dubon, etc.)
- Lens Options (Fixed Focus, Autofocus, Wide-Angle, Telephoto, etc.)
- SDK Support (Provides software support for secondary development and system integration)
- Housing Material (Metal/Plastic, supports waterproof, dustproof, and other industrial-grade designs)
- Module Solutions (Customizable embedded camera modules suitable for different application scenarios)
Q: How is the quality control?
A: All cameras undergo rigorous testing (EIS, low-light performance, durability) and comply with CE/FCC/RoHS.
Q: What is the lead time?
A:In-stock items: 3-7 days. Custom orders: 2-4 weeks (depending on specifications).
